Ductile Iron Pneumatic Butterfly Valve, A536, 36 IN, CL150
Key Specifications / Features
 Model No.: LV-BTV-20250108-03    Hits: 1
We are a leading manufacturer of pneumatic butterfly valves in China, crafted from high-quality ductile iron (ASTM A536 65-45-12) for enhanced durability. Featuring an ASTM A351 Grade CF8M disc and EPDM seat, these valves are designed to provide reliable performance in demanding applications. Available in 36-inch (DN900) size and Class 150 LB pressure rating, with RF ends for secure connections, our valves offer superior sealing and control. Ideal for industrial systems requiring robust flow regulation, these pneumatic butterfly valves deliver long-lasting, efficient operation.

Detail Information

Product Item: DI Butterfly Valves, Pneumatic Cylinder Actuator
Size: 36 Inch, DN900
Pressure: Class 150 LB, PN20
Body Material: ASTM A536 Grade 65-45-12/Ductile Iron Material
Disc Material: ASTM A351 Grade CF8M
Stem Material: ASTM A582 Grade 416
Shaft Seal Material: Buna N
Seat Material Material: EPDM
Bearing material: Lubricant Impregnated Bronze
Leakage Class: API 598
Operation: Pneumatic Cylinder Actuator
Connection End: RF ASME B16.47A
