BS 5351 Air Actuated Ball Valve, 2500LB, LCB
Key Specifications / Features
 Model No.: LV 14 TBV 14    Hits: 896
China Air Actuated Ball Valve: BS 5351 Air Actuated Ball Valves, 2500LB Pressure, API 608, API 6D, ASME B16.34, WCB, LCB, CF8, CF3, ISO 5208 Verified.

Detail Information

Valve Type: Pneumatic Actuated Ball Valve
Pressure Rating: Class 150~2500.
Size: NPS 2"~56".
Material: WCB, LCB, CF8, CF8M, CF3, CF3M, A105, LF2, F304, F316, F304L, F316L.
Design and Manufacture: API 608, API 6D, BS 5351, ASME B16.34.
Face-to-Face: ASME B16.10, API 6D.
End Connection: ASME B16.5, ASME B16.47, ASME B16.25.
Test and Inspection: ISO 5208, API 6D.
Operation Methods: Pneumatic Actuated (Pneumatically Operated, Air Actuated), Manual, Worm Gear, Electric Actuator, Pneumatic Actuator, Gas Over Oil Actuator are also available.
Body materials: stainless steel 304, 304L, 316, 316L.
