ASTM A216 WCB Ball Valve, 12 Inch, WCB, 300 LB, Pneumatic
Key Specifications / Features
Model No.: Hits: 4
Uncover our top-tier ON/OFF ball valve, complete with an efficient actuator, solenoid valve, and regulator, ensuring both seamless control and unmatched durability.
Detail Information
PNEUMATIC ACTUATOR ON/OFF BALL VALVE, REGULATOR & SOLENOID VALVE
(EEXD cable gland, shroud, and hanger tag plate) Full bore with metal seat according to ASME B16.10. Size and end connection: 12 inches in Class 300 RF ASME B16.5. Body material: ASTM A216GR WCB. Ball: 316SS. Coating and stem: Hard chrome and XM-19. H back seals: Graphite. Spring: Incoloy 825. Seat: 316SS with cobalt-based hard facing coating. Body gasket: PTFE. Packing: PTFE V-ring. Thrust bearing: Filled PTFE. Actuator: Pneumatic, single-acting cylinder with spring-return. Protection class: IP66. Function: Spring-to-close. Material of seals and bearing.
Prroduct Item: Pneumatic On/Off Ball Valve with Actuator, Solendid Valve & Regulator
Seat: SS 316
Size: 12 Inch, DN300
Pressure: Class 300 LB, PN50
Material: ASTM A216 Grade WCB
Ball: SS 316
Coating & Stem: Hard Chrome & XM-19
H Back Seals:
Graphite Sring: Incoloy 825
Body Gasket: PTFE
Pacing: PTFE V-ring
Standard: ASME B16.5
End Connection: RF
Seat: Metal
Coating: Protection Class IP66, Copneumatic, Single-acting Cylinder, Spring-return,
Function: Spring-to-close Material of Seals and Bearing
Balt-based hard facing
Thrust Bearing: Filled PTFE
Actuator: Pneumatic
