API 602, BS 5352 Y Pattern Globe Valve, 1/2-3 Inch
Key Specifications / Features
 Model No.: LV 22 FSGV 01    Hits: 34
Y Pattern Globe Valve Manufacturer: Y Globe Valves, API 602, BS 5352, 1/2-3 Inch, Class 150-2500 LB, RF, RTJ, BW, NPT, SW Ends, Soft Sealing.

Detail Information

API 602, BS 5352 Y Pattern Globe Valve

Design standard: API 602, BS 5352
Body material: Carbon steel, Stainless steel, duplex stainless steel, Alloy steel, Nickel alloy
Pressure range: Class 150-2500 LB
Nominal diameter: NPS 1/2-3 Inch
End connection: RF, RTJ, BW, NPT, SW
Mode of operation: Hand wheel, Gear box, Electric, Pneumatic, hydraulic device, Pneumatic-hydraulic device
Working temperature:-29℃ - 540℃

Product features:
1. Rapid opening and closing
2. Single structure, easy for repairing
3. When valve is full opened, the sealing surface suffered small friction from the working medium
4. Sealing surface without any abrasion when opening and closing, with long life
5. Soft sealing design can be chosen
6. Low emission packing can be chosen according to ISO 15848 requirements
7. Y pattern body design can be chosen
8. Pressure seal bonnet or welded bonnet can be chosen
9. Spring loaded packing can be chosen
